Products and solutions for e-mobility
Charging columns and charging stations
uesa offers the following products and solutions for e-mobility
• wall boxes and charging stations for cars, up to 22 kW, without measurement
• variable charging station designs for cars, with up to four charging points up to 22 kW, for up to four e-bikes,
e-scooters without quick charging, RFID registration, operation via display
• charging stations in the tank and rest area (transformer stations, cable distributors)
• charging stations for the needs of local transport companies or for trucks
• components for measuring current consumption in the medium and low voltage range
• custom project solutions
• realisation of e-mobility solutions for large customers.
You can order all listed product solutions including all planning services for grid
connection and they can be configured specifically to your needs.
The time is now! — Talk to us about e-mobility
AC charging pole compliant with calibration law for reliable charging
AC charging pole compliant with calibration law for reliable charging
The uesa/LS-2AC AC charging pole enables the simultaneous charging of up to two electric vehicles with an output of 22 kW each. It complies with current standards (IEC 61851) and is ideal for public and commercial charging infrastructures thanks to its calibration-compliant billing.
The robust, vandal-proof sheet steel housing (IP44, IK10) is weatherproof and available in individual RAL colours. Operation is simple via RFID reader or touch display, while an OCPP 1.6 interface ensures reliable backend integration. An integrated LTE router enables a stable connection.
In addition, the charging pole offers a status display, a service socket and a control cabinet heater to ensure reliable operation even in extreme temperatures (-25 to +55 °C). This versatile solution is perfect for companies, car parks and charging parks that require an efficient and legally compliant charging infrastructure.
technical dataAC charging pole compliant with calibration law with VNB measurement
AC charging pole with VNB metering in compliance with calibration law
The uesa/LS-2AC-VNB AC charging pole enables the simultaneous charging of two electric vehicles with 22 kW each and offers calibration law-compliant billing thanks to integrated VNB metering up to 30 kVA.
Its robust, vandal-proof sheet steel housing (IP44, IK10) is weatherproof and available in individual RAL colours. Operation is intuitive via an RFID reader or a touch display, while the OCPP 1.6 interface enables smooth connection to backend systems. An LTE router ensures stable communication.
With status displays, service socket, control cabinet heating and static load management (preset to 44 A/30 kVA), the charging pole offers a reliable solution for companies, car parks and charging parks. Thanks to precise meter reading, it is ideal for transparent and legally compliant billing in the public and commercial sectors.
technical dataAC charging bollard
AC charging bollard compliant with calibration law
The uesa/LP-2AC-FL-RFID AC charging bollard enables the simultaneous charging of up to two electric vehicles with an output of 22 kW each. Thanks to its calibration-compliant features and precise measurement, it is ideal for public and commercial use.
The housing made of glass fibre-reinforced plastic is weatherproof and available in various RAL colours. It is operated intuitively via RFID readers. An OCPP 1.6 interface ensures simple integration into existing backend systems, while an LTE router enables stable communication.
The charging bollard also features a status display, a service socket and a control cabinet heater for reliable operation at temperatures from -25 to +55 °C. Its compact design with integrated base makes it particularly space-saving and an ideal solution for car parks and businesses.
technical dataDC charging station
Powerful DC charging pole for efficient fast charging
The uesa/LS-2DC500 DC charging station enables the simultaneous fast charging of up to two electric vehicles with 240 kW power each and complies with current standards (IEC 61851). It is equipped with two cooled CCS fast-charging cables that deliver up to 500 A charging current and have practical cable holders with a parking position.
The robust sheet steel housing is galvanised, powder-coated and available in all RAL colours or with customised foiling. The integrated control system is conveniently operated via a 10-inch touch display and an RFID reader. An OCPP 1.6 interface ensures seamless integration into the backend, while an LTE router with antenna ensures reliable communication.
In addition, the charging pole offers easy readability of the DC counters, an integrated cooling unit, a status and error display and a control cabinet heater for reliable operation at temperatures from -25 to +55 °C. Thanks to the efficient and powerful charging option, it is ideal for in-house charging infrastructures in companies.
technical dataDC rectifier cabinet
DC rectifier cabinet for powerful charging infrastructures
The uesa/PM-1DC480/2DC240 DC rectifier cabinet is the ideal solution for supplying direct current to DC charging stations and offers a maximum output of 480 kW. Its robust outdoor distribution enclosure made of galvanised sheet steel is weatherproof (IP44) and available in individual RAL colours.
Thanks to powerful rectifier modules, two separately switchable DC outlets and integrated protection and monitoring systems, it guarantees a reliable power supply for high-performance charging systems. The active ventilation ensures optimum temperature regulation, while the modern communication interfaces (TCP-IP, CAN bus, Modbus) enable simple remote maintenance and control.
With flexible load management and an operating temperature range of -25 to +55 °C, this rectifier cabinet is the perfect choice for in-house charging infrastructures in companies that rely on powerful and efficient charging.
technical data
